Semi Automatic Capsule Filling Machine

Semi Automatic Capsule Filling Machine

Semi Auto Capsule Filling Machine

Our Semi Automatic Capsule Filling Machine is used to fill hard gelatin capsules (also known as 2-piece hard gel capsules) with powder, pellets, tablets, and/or microtablets. The filling capacity of this machine can be adjusted by modifying the number of rotations of the dosing disk. The powder feeder also has an auger to regulate the powder dosing. This improvement results in faster production, more accurate filling, safer operation, simple maintenance, super low noise, and easy to clean, all while being less labor intensive and meeting cGMP requirements. It has an infinite variable speed of filling table with independent power and fixed point filling that results in accurate dosage.

Our Semi Automatic Capsule Filling Machine will work with size 000, 00, 0, 1, 2, 3, 4 and 5 capsules. Only one operator is required, and operating training can be done in 10 minutes. A special design allows for changing parts for different size capsules within 30 minutes easily, simply, and precisely. The semi auto capsule filling machine has a very simple setup. The empty capsules are loaded into one hopper and the powder is then loaded into a separate hopper. This is an auger driven hopper, allowing a constant fill throughout each capsule over the capsule disk.

Simple Design
Only 1 operator is needed
Low-maintenance and cost-effective capsule filling machine
Quick and accurate change part set-up
Auger Powder Filler
Rotations of Capsule Disk can be adjusted.
Infinite variable speed of filling table
More accurate filling
Capsule filling Ejection Station

USF Semi Automatic Capsule Filler

Semi Automatic Capsule Filling Machine

Technical Specifications for Semi Automatic Capsule Filling Machine

# Model USF-Semi
1 Capacity Up to 25,000 capsules per hour
2 Capsule Sizes #000, #00, #0, #1, #2, #3, #4
3 Noise 63dBA
4 Power 220V 60Hz 3Ph or as required
