IBC Bin Lifter

Bin Lifter

IBC Pharma Bin Lift

UTG series Pharma Bin Lifter is primarily used in the pharmaceutical industry for transferring and loading powder and granules into other equipment such as blenders, mixers, mill sifters, tablet press, coating machine, capsule filling machine and so on. Utilizing the Bin Lifter optimizes the product flow and avoids dust and cross contamination. It is the most desirable transferring equipment in the pharmaceutical industry for solid dosage applications.

They are made of Austenitic stainless steel. All angles are cambered – there are no dead angles. They have non-concave/non-convex faces and no screws on the surface. The surface outside and inside are polished to high quality. Roughness degree inside is Ra = 0.2 µ m, and outside is Ra = 0.4 µ m. Silicon seal is used on the cover to provide an airtight seal. The custom butterfly discharge valve, which has no dead angles, is easy to dismantle and clean.

Control Panel for IBC BIN Lifter
Telescopic Post for transfering powders to next solid dosage stage.
Control Panel for Pharma Bin Lifter
IBC Lifter Pharma Bin
Pharma Bin Cone
Special Discharge Valve Eliminates Cross Contamination
IBC Pharma Bin
Butterfly Discharge Valve
Pharma Bin Butterfly Discharge Valve
