IBC Tank

Material Handling Equipment

IBC Tank Series ULD Tote/Containers are one of the most popular material handling containers used in the material handling flow of solid dosage in the pharmaceutical industry. Different types of manufacturing processes in solid dosage can be operated in the same tank. The frequent charging and discharging of materials is reduced thus avoiding dust and cross pollution in the pharma industry. Made of stainless steel 304 or optional 316L, the IBC Tanks are in conformity with GMP requirements.

Intermediate Bulk Containers (IBC Tanks) are made of Austenitic stainless steel. All angles are cambered – there are no dead angles. They have non-concave/non-convex faces and no screws on the surface. The inside and outside surfaces are polished to high quality. The roughness degree inside is Ra = 0.2 µ m, and outside is Ra = 0.4 µ m. Silicon seal is used on the cover to ensure the containers are airtight. The custom butterfly discharge valve, which also has no dead angles, is easy to dismantle and clean.

IBC Tank IBC Tank Layout

Intermediate Bulk Containers / Tote Containers

IBC Tank

# Model ULD-300 ULD-400 ULD-600 ULD-800 ULD-1000 ULD-1200 ULD-1500 ULD-1800 ULD-2000
1 A 800 800 1000 1000 1200 1200 1200 1200 1200
2 H 1120 1280 1360 1530 1600 1730 1860 1970 2250
3 Volume (L) 300 400 600 800 1000 1200 1500 1800 2000
