High Speed Blister Packaging Machine

Blister Packaging Machine

UBM-190C High Speed Blister Packing Machine

Model UBM-190 Blister Packaging Machine is a high speed production blister packing machine designed to pack all types of capsules, tablets, softgels, injection solution into blister packs. It is suitable for packing aluminum/PVC blister packs with option for Alu/Alu foil blister packs.

The spaces between the parts of forming, heat sealing and cutting can be adjusted as required. It is excellent for packing tablets or capsules of various sizes with high precision and efficiency. It is drawn by a mechanical hand with an adjustable stroke and easy and reliable operation.

Features:

  • The machine adopts module design. Each station can work individually.
  • SIEMENS Color Touch Screen Control Technology
  • SIEMENS PLC Control System
  • Easy format parts changeover and maintenance.
  • Complete set of detection system guarantees the medicine’s quality.
  • The machine meets cGMP standards.
  • Rugged design, durable, easy to operate and simple maintenance.

UBM-190C High Speed Packaging Machine

Blister Packaging Machine

# Model UBM-190C Alu/PVC Blister Packaging
1 Max Forming Depth 10mm
2 Max Forming Area 170×170mm
3 Max Material Width 190mm
4 Production Speed 120-150 strokes/min for Alu-PVC Packs
80-85 strokes/min for Alu-Alu Packs (optional)
200 Strokes/min (Max. Mechanical Speed)
5 Max Material Line Speed 8m/min
6 Power Supply 220V, 60Hz 3-Ph or as required
7 Consumption 9kw
8 Dimension (L x W x H) 3450×1250×2250mm3
9 Weight ~2,000 kg
