UND Gelatin Bloom Viscosity Tester

Gelatin Bloom Viscosity Tester

Bloom Test

UND Gelatin Bloom Viscosity Tester is used to measure the bloom viscosity of gelatin. The viscosity of gelatin solution is dependent on concentration, temperature, and Bloom value. The established method for the determination of viscosity involves efflux time measurement of 100ml of a standard test solution from a calibrated pipette viscometer. In certain cases viscosity is determined at concentrations at which the gelatin is to be used.

Meets the following standards

  • National standard (Food additive Gelatin) GB6783-94
  • American codex/No.22/VSPXX
  • Vocation standard (Gelatin for medicine) QB2354-98
  • Vocation standard (Industrial gelatin) QB/T1995-94
  • Vocation standard (Bone gelatin) QB/T1996-94
  • Vocation standard (Photographic gelatin)
  • QB/t1997-94

Bloom Test

Gelatin Gel Testing

# Model UND-1 UND-2
1 Test Range 0 ~ 9.99mPa • s 0 ~ 99.99mPa • s
2 Test Accuracy 0.05mPa • s 0.05mPa • s
3 Temperature Control 60.0°C 60.0°C
4 Travel Control Accuracy ± 0.1°C ± 0.1°C
5 Volume 100ml 100ml
6 Volume Accuracy ± 0.5ml ± 0.5ml
7 Recital Distance 152 ± 2mm 152 ± 2mm
8 Dimensions 400 x 300 x 450mm3 400 x 300 x 450mm3
9 Power 110V, 60Hz, 600W 110V, 60Hz, 600W
10 Weight 5kg (11 lbs) 5kg (11 lbs)
