United Pharmatek's Automatic Rotary Tablet Presses are mid-range mass production capacity, which is widely used in the pharmaceutical, herbal, nutraceutical, chemical and food industries to produce all types of round tablets and other irregular shapes tablets.
The pressing chamber is completely separated from the gear drive system. The parts in contact with the tablets are made of stainless steel, or the surface of those parts are polished and sterilized. The chamber is also sealed with organic glass for a better working environment. The gear system, the trace and the major friction parts are fully lubricated by the continual and concentrated lubrication devices.
It is ruggedly built, easy to monitor and adjust the operating pressure, thickness and feeding, and has a user-friendly design. Speed adjustable hand wheels, indicating lights and other control buttons are conveniently located. All contacted material parts and overall exterior of the machines are made of high quality stainless steel to meet the cGMP standard. Custom engraving on tablets is available upon request.
|1||Capacity||Up to 93,000 tablets per hour||Up to 110,100 tablets per hour||Up to 116,600 tablets per hour|
|2||Tooling||"D" TSM/EU1 Keyed Turret||"B" TSM/EU1 Keyed Turret||"BB" TSM/EU1 Keyed Turret|
|3||Max Tablet Diameter||(Round: 22mm) / (Shaped: 25mm)||(Round: 16mm) / (Shaped: 19mm)||(Round: 13mm) / (Shaped: 16mm)|
|4||Max Turret Speed||20~65 rpm||20~65 rpm||20~65 rpm|
|5||Machine Dimensions||35 x 32 x 71 in / 890 x 820 x 1,800 mm||35 x 32 x 71 in / 890 x 820 x 1,800 mm||35 x 32 x 71 in / 890 x 820 x 1,800 mm|
|6||Machine Weight||1400 KG||1400 KG||1400 KG|
|7||Power Supply||AC/220V/60Hz/3Ph/5Wires or as required||AC/220V/60Hz/3Ph/5Wires or as required||AC/220V/60Hz/3Ph/5Wires or as required|
